Technical Specs

Brands

 N/A
Autonics

Model

 N/A BS3

Type

 N/A Photomicro Sensor

Sensing Type

 N/A Through-Beam

Sensing Distance

 N/A 5 mm

Sensing Target

 N/A Opaque Materials

Minimum Sensing Target

 N/A ≥ 0.8 x 1.8 mm

Hysteresis

 N/A ≤ 0.05 mm

Response Time

 N/A Received Light: ≤ 20 µs, Interrupted Light: ≤ 100 µs

Response Frequency

 N/A 2 kHz

Light Source

 N/A Infrared Light-Emitting Diode (LED)

Peak Emission Wavelength

 N/A 940 nm

Operation Mode

 N/A Built-in Light ON / Dark ON

Indicator

 N/A Operation Indicator (Red)

Certification

 N/A

Features

N/A

  • Ultra compact size
  • Select appearance depending on the installation environment (K, F, R, U, L type)
  • Minimize malfunction and improve visibility
    • Minimize sensing part, gap and flush of the body to reduce malfunctions caused by a foreign substance
    • Built-in the operation indicator can be checked in many directions
  • Selectable models for the operation of indicator
    • Indicator turns ON under the light received condition
    • Indicator turns ON under the light interrupted condition
  • Resistant structure for shock and vibration
    • Shock 15,000 m/s² (approx. 1,500 G)
    • Vibration 10 to 2,000 Hz (1.5 mm double amplitude)
  • Selectable operation modes (Light ON/Dark ON)
