Unit of Measure

Technical Specs

Brands

 N/A
Autonics

Model

 N/A LE4S

Type

 N/A Timer

Function

 N/A MULTI Operation MULTI Time

Display Method

 N/A Liquid Crystal Display (LCD) (Backlight)

Permissible Voltage Range

 N/A 90 to 110 % of rated voltage

Insulation Resistance

 N/A 100 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 3,000 VAC ~ at 50/60 Hz for 1 minute

Vibration

 N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour

Vibration (Malfunction)

 N/A 0.5 mm double amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 10 minutes

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Shock (Malfunction)

 N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -10 to 55 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Mounting space saving with compact design: downsized by approx. 22% in depth compared to existing models (length of panel on the back side is 56 mm)
  • Available to set each value and time range separately when choosing Flicker (FK, FK I) or ON-OFF Delay (ON OFF D, ON OFF D I) output mode
  • Adds Flicker 1 mode (LE4SA)
  • Settable One-shot output time (0.01 to 99.99 sec) (existing model: fixed 0.5 sec)
  • Configurable time range (added 9.999 sec): settable by 0.001 sec unit
  • Selectable min. input time: 1 ms or 20 ms (LE4S)
  • Improved return time: 100 ms
  • Backlight ON / OFF function
  • Wide time range (0.01 sec to 9999 hour)
  • Lock setting function for saving setting data
  • Soft touch setting
  • High visibility display with backlight
