Technical Specs

Brands

 N/A
Autonics

Model

 N/A PMC-2HSP

Type

 N/A Motion Controller

Control Axes

 N/A 2 Axis

Motor Control

 N/A Pulse input stepper motor or servo motor

Drive Speed

 N/A 1 pps to 4 Mpps (1 to 8,000 pps x magnification 1 to 500)

Pulse Output Method

 N/A 1 pulse / 2 pulse output method (line driver output)

Operation Mode

 N/A Continuous Mode Index Mode Jog Mode Program Mode

Power Consumption

 N/A ≤ 6 W

Control Output

 N/A 50 mA

Index Steps

 N/A 64 step for each axis

Ambient Temperature

 N/A 0 to 45 ºC, Storage: -15 to 70 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 20 to 90% RH, Storage: 20 to 90% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • High speed independent 2 axis control with processing speed up to 4 Mpps
  • Supports linear and circular interpolation control
  • 17 control commands and up to 200 steps of operation programming
  • Supports various control interfaces (USB, RS232C, RS485, Parallel I/F)
  • Multiple control of up to 32 axes (16 units) with RS485 communication (Modbus RTU)
  • 4 operation modes: Jog mode, Continuous mode, Index mode, Program mode
  • Symmetrical/asymmetrical trapezoid or S-shaped acceleration/deceleration control
