Technical Specs

Brands

 N/A
Autonics

Model

 N/A SPC

Type

 N/A Controller

Control Phase

 N/A Single-Phase

Insulation Resistance

 N/A 100 MΩ (500 VDC, Megger)

Cooling Method

 N/A Natural Air Cooling

Dielectric Strength

 N/A Between the charging part and the case: 3,000 VAC~50/60 Hz for 1 minute

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Shock (Malfunction)

 N/A 100 m/s² (≈ 10 G) in each X, Y, Z direction for 3 times

Vibration

 N/A 0.75 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 1 hour

Vibration (Malfunction)

 N/A 0.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 10 minutes

Ambient Temperature

 N/A 0 to 50 ºC, Storage: -25 to 65 ºC (No freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Indicator

 N/A Output Indicator (Green)

Certification

 N/A

Features

N/A

  • Various and simple input specification
    • DC 4 - 20 mA, 1 - 5 VDC, External 24 VDC
    • External adjuster (1 kΩ)
    • External contact (ON / OFF)
  • Various function
    • Out ADJ (output limit) function
    • Soft Start function (except for ON/OFF control type)
    • Out display function.
    • 50 / 60 Hz automatic converting function
  • Various control by mode switches
    • Phase control
    • Cycle control (zero cross turn-on)
    • ON/OFF control (zero cross turn-on)
