Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SPRM |
Type |
N/A Controller |
Control Phase |
N/A Single-Phase 3 Channel or 3-phase |
Direct Current (DC) Power Supply Voltage |
N/A 24 V |
Minimum Load Current |
N/A 1 A |
Insulation Resistance |
N/A ≥ 200 MΩ (500 VDC, Megger) |
Power Consumption |
N/A ≤ 15 W |
Permissible Voltage Range |
N/A 90 to 110 % of rated voltage |
Dielectric Strength |
N/A Between the charging part and the case: 3,000 VAC~50/60 Hz for 1 minute |
Vibration |
N/A 0.5 mm double amplitude at frequency of 5 to 55 Hz in each X, Y, Z direction for 2 hours |
Vibration (Malfunction) |
N/A 0.5 mm double amplitude at frequency of 5 to 55 Hz in each X, Y, Z direction for 10 minutes |
Ambient Temperature |
N/A -10 to 40 ºC, Storage: -20 to 80 ºC (No freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Certification |
N/A
 |
Features
|
|
