Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PA10 |
Type |
N/A Controller |
Power Consumption |
N/A ≤10 VA (12 VDC/ 200 mA load) |
Output Response Time |
N/A Relay output: ≤ 10 ms, Transistor output: ≤ 0.05 ms |
Relay Life Cycle |
N/A
Mechanical: Min. 10,000,000 times Electrical: Min. 100,000 times (250 VAC~3 A resistance load) |
Dielectric Strength |
N/A 2,000 VAC~50/60 Hz for 1 minute |
Ambient Temperature |
N/A -10 to 55 ºC, Storage: -25 to 60 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation) |
Certification |
N/A
 |
Features
|
|
