Technical Specs

Brands

 N/A
Autonics

Model

 N/A TMH

Type

 N/A Temperature Controller

Permissible Voltage Range

 N/A 90 to 110 % of rated voltage

Display Type

 N/A None- parameter setting and monitoring is available at external devices

Memory Retention

 N/A ≈ 10 years (Non-volatile Semiconductor Memory type)

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, storage : 35 to 85% RH (No freezing or Condensation)

Insulation Resistance

 N/A 100 MΩ (500 VDC, Megger)

Power Consumption for Maximum Load

 N/A ≤ 5 W

Noise Immunity

 N/A Square shaped noise by noise simulator (pulse width 1 µs) ±0.5 kV

Certification

 N/A

Features

N/A (Common)

  • Easy maintenance with detachable body and base terminal
  • Power supply and communication with expansion connectors (up to 32 units)
(TMH2/4 Series (Control Module))
  • Multi-channel (2-channel/4-channel) input and output control: Expandable up to 32 units (64-channels/128-channels)
  • 50 ms high-speed sampling rate and ±0.3% measurement accuracy
  • Simultaneous heating and cooling control function and auto/manual control mode (patent: Korea Patent Registration 10-1624105)
(TMHA (Analog Input / Output Option Module))
  • 4 channels, various input types/temperature ranges/transmission outputs
  • 50 ms high-speed sampling rate and ±0.3% measurement accuracy
(TMHE (Digital Input / Alarm Output Option Module))
  • 8 digital inputs / 8 alarm outputs
(TMHCT (CT Input Option Module))
  • 8 CT inputs
(TMHC (Communication Modules))
  • Allows connection of control modules and option modules to master devices
  • Connect up to 32 control/option modules per communication model
