Technical Specs

Brands

 N/A
Dynapar™

Model

 N/A AI25 EtherCAT

Type

 N/A Absolute Encoder

Code

 N/A Absolute Optical

Resolution (Single-Turn)

 N/A 10 to 22 bits

Resolution (Multi-Turn)

 N/A 12 bits

Linearity

 N/A ± 1/2 LSB up to 14 Bit

Typical Absolute Accuracy (±)

 N/A 35 in

Typical Repeatability (±)

 N/A 10 in

Certification

 N/A

Key Features

N/A

  • Best Shock and Vibration Resistance in its Class (400G shock, 30G vibration)
  • High Speed 10,000 RPM Continuous Operation (12,000 RPM Short Term)
  • Extremely Fast Cycle Times (62.5 µs)
  • Extended Temperature Range ( -40ºC to +85ºC)
  • Customizable Resolution and Mounting Style
  • Device Data: Position, Speed, Temperature, Diagnostic Data, Alarms
  • Device Configuration: Resolution, Total Measuring Range, Preset, Offset, Direction, Position, Limits, Scaling, Residual Value Function, Speed Limits, Temperature Limits
