Technical Specs

Brands

 N/A
Dynapar™

Hengstler

Model

 N/A AX70/AX71

Type

 N/A Absolute Encoder

Code

 N/A Absolute Optical

Certification

 N/A

Mechanical

Shaft Diameter (Solid Shaft)

 N/A 10 mm

Shaft Material

 N/A Stainless Steel

Mounting

 N/A Clamping Flange

Starting Torque

 N/A ≤ 1 N·cm

Maximum Axial Shaft Load

 N/A 40 N

Maximum Radial Shaft Load

 N/A 100 N

Key Features

N/A

  • Up to 22 bit of Single-turn, 12 bit of True Multi-turn Absolute Positioning
  • ATEX Certification for Explosion Proof Requirements
  • Ingress Protection up to IP67
  • Stainless Steel or Aluminum Housing
  • Multiple Communication Options
