Technical Specs

Brands

 N/A
Dynapar™

NorthStar™

Model

 N/A EN42

Type

 N/A Rated Encoder

Code

 N/A Incremental

Resolution

 N/A 1 to 5,000 pulses/rev

Symmetry

 N/A 180º ±30º Electrical

Index

 N/A 180º default gated to B low

Quadrature Phasing

 N/A 90º ±30º Electrical

Phase Sense

 N/A A leads B for CCW shaft rotation viewing the shaft clamp end of the encoder

Format

 N/A Two channel quadrature (AB) with optional Index (Z) and complementary outputs

Waveforms

 N/A Square wave with rise and fall times less than 1 microsecond into a load capacitance of 1000 pf

Certification

 N/A
Certification-EN42

Features

N/A

  • Triple Certified Encoder for Hazardous Locations
  • Encapsulated Electronics with Increased Safety Interface for Zone 1 Use Eliminates Need for I.S. Barrier
  • High Current Line Driver for Long Cable Runs
  • 50G Shock and 20G Vibration Tolerant
