Technical Specs
Brands |
N/A
 Dynapar™ |
Model |
N/A F14 |
Type |
N/A Small Servo Motor |
Code |
N/A Incremental with Commutation Option Optical |
Resolution |
N/A 1000 to 5000 ppr incremental with 4, 6 and 8 pole commutation channels |
Accuracy |
N/A Incremental: ±2.5 arc-mins. max. edge to any edge; Commutation: ±6 arc-mins. max. |
Minimum Edge Separation |
N/A A to B is 45º |
Index to U Channel |
N/A ±1º mech. index pulse center to U channel edge. |
Index Pulse Width |
N/A 90º gated A and B high; (180º gated B high gating options available - consult factory) |
Certification |
N/A
 |
