Technical Specs

Brands

 N/A
Dynapar™

NorthStar™

Model

 N/A ST85

Type

 N/A Bearingless Encoder

Code

 N/A Incremental Magnetic

Resolution

 N/A 64 to 2,048

Phasing Sense

 N/A A leads B for Counter-Clockwise rotation (CCW) viewing encoder-mounted end

Quadrature Phasing

 N/A 90º ±45º

Symmetry

 N/A 180º ±54º

Index

 N/A Less than phase A/B pulse width

Number of Output Modules

 N/A Dual Single

Certification

 N/A

Key Features

N/A

  • Redesigned Using Our Revolutionary Sensor Technology to Provide a Large Air Gap of 0.060"
  • Redesigned Circuitry for On-Board Diagnostics with LED and Alarm Output
  • Bearingless Design Mounts to 140 C-Face Motors
  • Dual C-Face Versions Available for "Sandwich" Mounting
  • Anodized Aluminum Housing with Field-Serviceable Connector
  • Single or Dual Isolated Outputs Available
