The sleek design of the Model 775 Thru-Bore Series Accu-Coder™ makes form and function a successful reality. The slim profile and Thru-Bore design, makes installation easy by simply slipping the bore over motor shafts up to 1.375" in diameter. The advanced Opto-ASIC based electronics provide the superior noise immunity necessary in many industrial applications. With a variety of bore sizes, resolutions, and connector types, application possibilities are endless.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 775

Type

 N/A Encoder

Maximum Shaft Speed

 N/A 6000 rpm. Higher speeds may be achievable, contact Customer Service.

Housing

 N/A All Metal Construction

Moment of Inertia

 N/A 3.3 x 10-3 oz-in-sec2 Typical

Storage Temperature

 N/A -25 to 100 ºC

Non-Condensing Relative Humidity

 N/A 98 %

Vibration

 N/A 10 g @ 58 to 500 Hz

Shock

 N/A 50 g @ 11 ms duration

Common Applications

N/A Motor Feedback, Velocity & Position Control, Food Processing, Robotics, Material Handling

Features

N/A

  • Thru-bore design for easy mounting
  • Bore options to 1.375"
  • Incorporates Opto-ASIC technology
  • Resolutions to 4096 CPR
  • 100º C Operating temperature available
  • CE marking available
