The TR3 Heavy Duty Tru-Trac™ is an integrated, heavy duty encoder and spring loaded measuring wheel assembly all in one unit. Available in both single or optional dual-wheel format, the TR3 Heavy Duty Tru-Trac™ is a versatile solution for tracking velocity, position or distance over a wide variety of surfaces in many industrial applications. Its spring loaded torsion arm provides a simple-to-adjust torsion load, allowing the TR3 Heavy Duty Tru- Trac™ to be mounted in any orientation, even upside-down. The TR3 Heavy Duty Tru-Trac™ housing is an all metal work horse, specifically designed to take on your toughest application environments at operating speeds up to 3000 feet per minute. Just one look and it’s easy to see the TR3 Heavy Duty Tru-Trac™ is the ideal solution for countless applications.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A TR3

Type

 N/A Linear Measurement Encoder

Housing

 N/A Powder Coated Aluminum

Maximum Linear Speed

 N/A 3000 FPM not to exceed a maximum shaft speed of 6000 rpm.

Shaft Material

 N/A Stainless Steel

Radial Shaft Load

 N/A Up to 10 lb max. Controlled by spring torsion feature

Standard Wheel Width

 N/A 3/4 in

Storage Temperature

 N/A -25 to 85 ºC

Non-Condensing Relative Humidity

 N/A 98 %

Vibration

 N/A 10 g @ 58 to 500 Hz

Shock

 N/A 80 g @ 11 ms duration

Common Applications

N/A Lumber, Corrugated, Converting, Metal Roll Forming, Paper Monitoring, Glue Dispensing, Linear Material Monitoring, Conveyor Systems, Printing, Labeling, Mining, Construction

Features

N/A

  • Integrated heavy duty encoder and measuring wheel in one
  • Spring-loaded torsion arm for quick wheel pressure adjustments
  • Easily installed in a vertical, horizontal, or upside-down orientation
  • Operates over a variety of surfaces at speeds up to 3000 feet per minute
  • Integrated module simplifies your system design, reducing cost
