The high-accuracy RI76 hollow shaft incremental encoder has been specially designed for large shaft diameters up to 42 mm. The housing diameter is only 76 mm, which makes this encoder ideal for use in motors, lifts and printing machines.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A RI76TD

Type

 N/A Incremental Encoder

Number of Pulses

 N/A 10 100 1000 1024 1250 1500 20 200 2000 2048 25 250 2500 300 3000 360 3600 5 50 500 60 600 720

Note for Number of Pulses

 N/A Other number of pulses on request.

Certification

 N/A

Mechanical

Housing Diameter

 N/A 76 mm

Shaft Diameter

 N/A 15 mm16 mm18 mm20 mm24 mm25 mm27 mm28 mm30 mm32 mm38 mm40 mm42 mm

Flange (Mounting of Housing)

 N/A Tether

Mounting of Shaft

 N/A Front clamping ring, Rear clamping ring

Protection Class Shaft Input (EN 60529)

 N/A Ingress Protection (IP40) Ingress Protection (IP64) (front & rear)

Protection Class Housing (EN 60529)

 N/A Ingress Protection (IP65)

Maximum Speed

 N/A For Ø 15 to 25 mm at 70 ºC and IP64: max. 3,600 rpm
for Ø >25 to 42 mm at 70 ºC and IP64: max. 1,800 rpm
for Ø 15 to 42 mm at 70 ºC and IP40: max. 6,000 rpm
for Ø 15 to 42 mm at 100 ºC always: max. 1,800 rpm

Typical Starting Torque

 N/A 3 to 10 N·cm

Note for Typical Starting Torque

 N/A Depending on version

Approximate Moment of Inertia

 N/A 140 to 420 g/cm²

Note for Approximate Moment of Inertia

 N/A Depending on version

Housing Material

 N/A Aluminum

Shaft Connection

N/A Shaft fixing is done through a clamping ring either on the flange or cap side. As a rule, flange side clamping is better for smaller motors as the available shaft stub is correspondingly shorter.

On the other hand, cap side clamping is easier when there is sufficient shaft length available

Mounting Necessities

N/A In order to compensate for axial and radial shaft eccentricity as well as any angle offset, the encoder flange must not be rigidly mounted. Please mount the flange with a flexible stator coupling (e.g. hub shaft with tether) as torque support.

There are two flexible mounting plates:

  • A flexible hub shaft with tether (A) for higher levels of play and lower requirements for accuracy.
  • A rigid hub shaft with tether (N) for reduced play and rigid connection with Reduced swing angle. This is suitable in the case of higher accuracy and dynamics requirements.

Applications

N/A Motors, printing machines, lifts

Features

N/A

  • Easy installation by means of clamping ring front or rear
  • Operating temperature up to 100ºC
  • 10,000 pulses "true-read"
  • Condition Monitoring through Alarm-Signal
