DIN Width 72 x Height 72, Width 144 x Height 72 mm
Unit of Measure

Technical Specs

Brands

 N/A
Autonics

Model

 N/A F/L

Type

 N/A Counter

Digit

 N/A 8-Digit

Allowable Voltage Range

 N/A 90 to 110% of Rated Voltage

Maximum Counting Speed

 N/A 1 cps30 cps2,000 cps5,000 cps

One-Shot Output Time

 N/A 0.05 to 5 sec

Memory Protection

 N/A Approximate 10 years (When using non-volatile semiconductor memory)

Insulation Resistance

 N/A 100 MΩ (at 500 VDC megger)

Features

N/A

  • 8 digits counter: Selectable Up, Down, Up/Down mode
  • Selectable voltage input (PNP) or no-voltage input (NPN)
  • Decimal point setting (Fixed decimal point of display)
  • Wide range of power supply : 100-240VAC 50/60Hz, 12-24VAC/DC(Option)
  • Built-in Microprocessor
