Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A E40 |
Type |
N/A Encoders |
Housing Diameter |
N/A 40 mm |
Resolution |
N/A 1 pulses/rev10 to 5,000 pulses/rev12 pulses/rev2 pulses/rev5 pulses/rev |
Maximum Response Frequency |
N/A 300 kHz |
Maximum Allowable Revolution |
N/A 5,000 rpm |
Starting Torque |
N/A
E40S: ≤ 0.004 N·m E40H, E40HB: ≤ 0.005 N·m |
Moment of Inertia |
N/A 4 x 10-6 kg·m²≤ 40 g/cm² |
Allowable Radial Shaft Load |
N/A ≤ 2 kgf |
Allowable Thrust Shaft Load |
N/A ≤ 1 kgf |
Dielectric Strength |
N/A Between all charging part and case: 750 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Ambient Temperature |
N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation) |
Certification |
N/A
 |
