Technical Specs

Brands

 N/A
Autonics

Model

 N/A M4V

Type

 N/A Meter

Display Method

 N/A 7-Segment (Red) Light-Emitting Diode (LED) (Character Height: 14 mm)

Display Cycle

 N/A 0.5 sec

Power Consumption

 N/A ≤ 2 W

Dielectric Strength

 N/A Between the charging part and the case: 2,000 VAC~ 50/60 Hz for 1 minute

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Various input options: 0 - 2 VDC, 0 - 10 VDC, 1 - 5 VDC, DC 0 - 1 mA, DC 4 - 20 mA
  • High / low-limit display scale function
  • Display range: -999 to 9999
  • Display accuracy: F.S ± 2 % rdg ± 1-digit
  • Error display function
  • Built-in microprocessor
