Technical Specs

Brands

 N/A
Autonics

Model

 N/A M4W

Type

 N/A Meter

Display Scale

 N/A 1999

Display Method

 N/A 7-Segment (Red) Light-Emitting Diode (LED) (Character Height: 14 mm)

Operation Method

 N/A Dual Integral Method

Sampling Cycle

 N/A 300 ms

Dielectric Strength

 N/A Between the charging part and the case: 3,000 VAC~ 50/60 Hz for 1 minute

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -25 to 65 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 85% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Max. display value: 1999
  • Auto-zero function and hold display value function
  • Linear display based on input specification
  • Display output values (0 - 10 VDC) from power converters (options available for DC 4 - 20 mA, 1 - 5 VDC)
  • RMS or AVG value selection (AC voltage)
  • 7-segment LED display
  • DIN standard size models
