Technical Specs

Brands

 N/A
Autonics

Model

 N/A PTF30

Type

 N/A Transmitter

Sampling Period

 N/A 300 ms

Vibration

 N/A 0.75 mm amplitude at frequency of 5 to 55 Hz in each X, Y, Z direction for 2 hours

Protection Structure

 N/A Ingress Protection (IP67) (International Electrotechnical Commission (IEC Standard))

Display Type

 N/A 12 Segment LCD, 4 digit

Setting Method

 N/A Front key

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC for 1 minute

Ambient Temperature

 N/A -20 to 70 ºC, Storage: -20 to 80 ºC (No Freezing or Condensation)

Certification

 N/A

Applications

N/A Indoor heating, water supply and sewage, and incinerator and small and medium sized projects

Features

N/A

  • Minimized disturbance effect by improving noise resistance
  • Excellent corrosion resistance with stainless steel housing
  • High accuracy ±0.2％ F.S.
  • Various functions
    • User input range, display scale, output scale, digital filter, multi display selection, abnormal operation display, TUF (Two Unit Function), etc.
  • Explosion-proof specification: Ex d IIC T6
  • Protection structure: IP67 (IEC standard)
