Technical Specs

Brands

 N/A
Autonics

Model

 N/A MGAM50

Type

 N/A Encoders

Maximum Allowable Revolution

 N/A 3,000 rpm

Starting Torque

 N/A ≤ 0.0069 N·m

Moment of Inertia

 N/A 8 x 10-6 kg·m²≤ 80 g/cm²

Allowable Radial Shaft Load

 N/A 10 kgf

Allowable Thrust Shaft Load

 N/A 2.5 kgf

Dielectric Strength

 N/A Between the charging part and the case: 750 VAC~ 50/60 Hz for 1 minute

Vibration

 N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction

Shock

 N/A ≲ 50 G

Ambient Temperature

 N/A -10 to 70 ºC, Storage: -25 to 85 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85% RH, Storage: 35 to 90% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • High accuracy in harsh environments including shock, vibration, dust, and humidity (compared to optical encoders)
  • Longer service life compared to optical encoders
  • Output code: binary
  • Output interface options: Parallel, SSI (Synchronous Serial Interface)
  • 23-bit (8,388,608) total resolution
    • - 10-bit single-turn (1024 divisions)
    • - 13-bit multi-turn (8192 revolutions)
  • Power supply: 12 - 24 VDC, ± 5%
  • Overflow alarm (OVF) function
  • IP50 protection structure (IEC standard)
