Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A Ai-M |
Type |
N/A Stepper Motor |
Insulation Resistance |
N/A Between the motor coil and the case: ≥ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the all charging part and the case: 500 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 1.5 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Ambient Temperature |
N/A 0 to 50 ºC, Storage: -20 to 70 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 20 to 85% RH, Storage: 15 to 90% RH (No Freezing or Condensation) |
Certification |
N/A
 |
