Technical Specs

Brands

 N/A
Autonics

Model

 N/A VC

Type

 N/A Camera

Resolution

 N/A 5 MP (2,560 x 2,048)
Frame Per Second1 N/A 16 fps

Shutter

 N/A Global Shutter

Current Consumption

 N/A ≤ 1 A

Vibration

 N/A 1.5 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times

Ambient Temperature

 N/A -0 to 45 ºC, Storage: -30 to 80 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 0 to 95% RH, storage: 0 to 95% RH (No freezing or Condensation)

Certification

 N/A

Features

N/A

  • Various inspection functions
  • Inspection simulator function
  • Set up to 64 separate work group (32 inspection points per work group)
  • Save data to FTP servers
  • Support smart camera software (atVision)
    • Inspection simulator function, manage parameters and work group,
    • inspection results monitoring, send data to FTP, multilingual support, etc.
  • IP67 protection structure (IEC standard)
  • C-Mount type
  • Gigabit Ethernet communication
  • 1 The number of camera frames per second can be different by image setting or inspection item.
