Technical Specs

Brands

 N/A
Autonics

Model

 N/A AS

Type

 N/A Long Sensing Distance Type Proximity Sensor

Sensing Distance

 N/A 50 mm ±10%

Hysteresis

 N/A Maximum 15% of Sensing Distance

Standard Sensing Targe (Iron)

 N/A 150 x 150 x 1 mm

Setting Distance

 N/A 0 to 35 mm

Direct Current (DC) Power Supply Voltage

 N/A 12 to 48 V

Direct Current (DC) Operating Voltage

 N/A 10 to 65 V

Maximum Current Consumption

 N/A 10 mA

Certification

 N/A

Features

N/A

  • Able to detect up to as 50 mm
  • Improved the noise resistance with dedicated IC
  • Reverse power polarity, surge, overcurrent protection
  • Wide range of power supply : 12-48VDC (Voltage range:10-65VDC)
  • Simultaneous output of Normal Open+Normal Close
  • Built-in power indicator and operation indicator
  • IP67 rated waterproof structure (IEC standard)
