Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A LPD |
Type |
N/A Sensor |
Function |
N/A Positioning |
Detection Type |
N/A Inductive |
Response Time |
N/A ≤ 30 ms |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the charging part and the case: 500 VAC ~ at 50/60 Hz for 1 minute |
Vibration |
N/A 1.0 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 30 minutes |
Shock |
N/A Half-Sinus, 30 g , 11 ms (EN 60068-2-27, Shock) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (A Non Freezing or Condensation Environment) |
Certification |
N/A
 |
Features
|
|
