Technical Specs

Brands

 N/A
Autonics

Model

 N/A BYD

Type

 N/A Photoelectric Sensor

Insulation Resistance

 N/A ≥ 20 MΩ (500 VDC, Megger)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC ~ 50/60 Hz for 1 minute

Vibration

 N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours

Shock

 N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times

Protection Circuit

 N/A Reverse power protection circuit, output short overcurrent protection circuit

Certification

 N/A

Features

N/A

  • Easy installation by compact size
  • Superior detection not affected by color of target (convergent reflective type )
  • Operation indicator is located on the top (BYD30-DDT-U, BYD50-DDT-U)
  • Easy to adjust the response time via timer function (OFF Delay Time: 0.1 to 2 sec)
  • Reverse power protection circuit, output short overcurrent protection circuit
