Technical Specs

Brands

 N/A
Autonics

Model

 N/A PSQ

Type

 N/A Pressure Sensor

Power Supply

 N/A 12 - 24 VDC (ripple P-P: ≤ 10 %)

Allowable Voltage Range

 N/A 90 to 110% of Rated Voltage

Current Consumption

 N/A ≤ 50 mA (analog output model: ≤ 70 mA)

Control Output

 N/A Negative-Positive-Negative (NPN) Positive-Negative-Positive (PNP) open collector output

Direct Current (DC) Load Voltage

 N/A ≤ 30 V

Load Current

 N/A ≤ 100 mA

Direct Current (DC) Residual Voltage

 N/A ≤ 2 V

Hysteresis

 N/A Different by output operation mode (parameter)

Dielectric Strength

 N/A Between the charging part and the case: 1,000 VAC 50/60 Hz for 1 minute

Vibration

 N/A 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 30 to 80% RH, Storage: 30 to 80% RH (No Freezing or Condensation)

Certification

 N/A

Features

N/A

  • Pressure measurement of any gas, liquid or oil [fluid type] except substances which may corrode stainless steel 316L
  • Dual display for simultaneous display of process value (PV) and setpoint value (SV)
  • Secondary (SV) display : setpoint value, pressure unit, or display-OFF
  • Switch between NPN and PNP open collector output via parameter configuration
  • 3-Color main (PV) display (RUN mode : green/red, parameter setting mode : orange)
  • 12-Segment LCD display capable of diverse alphanumeric characters
  • Measurement range : -100.0 to 100.0 kPa /-100 to 1000 kPa (Pneumatic type : compound pressure, Fluid type : sealed gauge pressure)
  • Analog output : voltage (1-5VDC), current (DC 4-20mA)
  • Copy parameter settings function
  • External input : Auto-Shift, Remote, Hold (PSQ-models only)
  • Forced output control mode for device testing and inspection
  • Display resolution : 0.1 kPa /1 kPa (by model)
  • One-touch connector type for easy wiring and maintenance
  • Password lock for parameter configuration settings
