Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PR |
Type |
N/A Sensor |
Power Supply |
N/A 12 - 24 VDC (ripple P-P: ≤ 10 %), operating voltage: 10 - 30 VDC |
Leakage Current |
N/A ≤ 0.6 mA |
Control Output |
N/A 2 to 100 mA |
Residual Voltage |
N/A ≤ 3.5 V (non-polarity 01): ≤ 5 V) |
Protection Circuit |
N/A Surge protection circuit, output short over current protection circuit, reverse polarity protection |
Insulation Resistance |
N/A ≥ 50 MΩ (500 VDC megger) |
Dielectric Strength |
N/A Between the charging part and the case: 1,500 VAC 50/60 Hz for 1 minute |
Vibration |
N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -25 to 70 ºC, Storage: -30 to 80 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 95% RH, Storage: 35 to 95% RH (No Freezing or Condensation) |
Connection |
N/A Cable Connector Type Cable Type Connector Type Model |
Certification |
N/A
 |
