Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PFI |
Type |
N/A Sensor |
Sensing Side Length |
N/A 25 mm |
Sensing Distance |
N/A 8 mm |
Setting Distance |
N/A 0 to 5.6 mm |
Hysteresis |
N/A ≤ 10 % of sensing distance |
Standard Sensing Targe (Iron) |
N/A 25 x 25 x 1 mm |
Response Frequency |
N/A 200 Hz |
Affection by Temperature |
N/A ≤ ± 10 % for sensing distance at ambient temperature 20 ºC |
Indicator |
N/A Operation Indicator (Red) |
Unit Weight |
N/A 70 g |
Dielectric Strength |
N/A Between the charging part and the case: 1,500 VAC 50/60 Hz for 1 minute |
Vibration |
N/A 1 mm double amplitude at frequency 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Ambient Temperature |
N/A -25 to 70 ºC, Storage: -30 to 80 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 95% RH, Storage: 35 to 95% RH (No Freezing or Condensation) |
Certification |
N/A
 |
