Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A UTR |
Type |
N/A Controller |
Insulation Resistance |
N/A ≥ 50 MΩ (500 VDC, Megger) |
Dielectric Strength |
N/A Between the charging part and the case 1,000 VAC~50/60 Hz for 1 minute |
Vibration |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
Shock |
N/A 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -25 to 70 ºC, Storage: -40 to 85 ºC (No Freezing or Condensation) |
Connection |
N/A Connector Models |
Connector Specification |
N/A M12 5-Pin Plug Connector |
Certification |
N/A
 |
Features
|
|
