Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SFN |
Type |
N/A Switch |
Operating Frequency |
N/A 100 Hz |
Insulation Resistance |
N/A ≥ 50 MΩ (at 500 VDC, Megger) |
Vibration (Malfunction) |
N/A 1.0 mm amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 10 minutes |
Shock |
N/A 300 m/s² (≈ 20 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 300 m/s² (≈ 20 G) in each X, Y, Z direction in output ON/OFF status for 3 times |
Ambient Temperature |
N/A -10 to 55 ºC, Storage: -20 to 60 ºC (No freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (A Non Freezing or Condensation Environment) |
Power Consumption |
N/A ≤ 400 mA |
Dielectric Strength |
N/A 1,500 VAC~50/60 Hz for 1 minute |
Vibration |
N/A 1.0 mm amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 2 hours |
Certification |
N/A
 |
