Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A SF2ER |
Type |
N/A Switch |
Diameter |
N/A 22 mm25 mm |
1 Contact Operating Power |
N/A 3.0 to 8.0 N |
Rotation Angle |
N/A Clock Wise (CW) 52º |
Allowable Operation Frequency |
N/A Electrical: 20 times/minute Mechanical: 20 times/minute |
Life Cycle |
N/A Electrical: Minimum 100,000 times Mechanical: Minimum 250,000 times |
Vibration |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 2 hours |
Vibration (Malfunction) |
N/A 1.5 mm double amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 10 minutes |
Shock |
N/A 1,000 m/s² (≈ 100 G) in each X, Y, Z direction for 3 times |
Shock (Malfunction) |
N/A 250 m/s² (≈ 25 G) in each X, Y, Z direction for 3 times |
Ambient Temperature |
N/A -20 to 65 ºC, Storage: -40 to 70 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH, Storage: 35 to 85% RH (At No Freezing or Condensation) |
Certification |
N/A
 |
